Completely Plug-and-play with Hikvision, Uniview, TVT, LTS, Viewtron, GW Security, ENS Titanium, ENS Emerald, ENS-H, and many more.
Key Features:
• 1/2.7" CMOS sensor.
• 8MP HD resolution 3840×2160 4K output.
• Ultra low illumination 0.01Lux.
• Day/Night (ICR), AWB, 2D/3D-DNR, IR-CUT.
• D-WDR, Motion Detection, Human and Vehicle Detection, Privacy Mask, Flip.
• RTSP and Onvif 17.06 comptible.
• H.265/ H.264 dual-stream media server.
• Easy-to-use P2P Cloud Service.
• Multi web browser, PC Client, mobile APP remote access.
• RJ45 100mbps network port, IEEE802.3af PoE.
• Lightning protection 4000V.
• Strong water-proof housing, IP67.
• 2 pcs IR&warm-light Led, Light distance 20-30 meters.
• HD 2.8mm F1.6 fixed lens.
• Two-Way audio, SD slot,Reset button.
THREE NIGHT VISION MODES
ADVANCED MOTION DETECTION
HUMAN & VEHICLE DETECTION
REMOTE ACCESS FROM MOBILE AND DESKTOP
Product Specifications:
|
Model |
CPV-SMCFD-4KSAI |
|
Camera |
|
Image Sensor |
1/2.7" 8MP CMOS |
|
Effective Pixels |
3840x2160 |
|
Electronic Shutter |
AUTO/Manual: 1/10s - 1/10000s, shutter threshold |
|
Min. Illumination |
0.01Lux@F1.2(AGC ON), 0 Lux IR on |
|
Day/Night |
Auto/Color/(B/W)/Timing |
|
WDR |
Digital WDR |
|
White Balance |
Auto Manual |
|
BLC/ HLC |
Support |
|
DNR |
G.711 (U/A)2D/3D DNR |
|
Light Control |
Auto/Manual, Mode switch, Brightness level, OFF, Light ON Illumination |
|
Lisense Plate Mode |
Yes |
|
Other |
Milti-lines, OSD, Custom Title, Privacy Mask, Flip, Reset Button |
|
Encode |
|
Video Standard |
H.264/ H265/ H.265+ |
|
Video Resolution |
Main Stream: 20fps@3840x2160 ,25fps@3072x2048 ,30fps@5MP / 2560x1440 / 2304x1296/ 1920x1080/ 1280x720
Sub Stream: 30fps@D1 / VGA(640x480) / 640x360, 480x360, CIF(352x288) |
|
Video Bitrates |
512Kbps - 12Mbps, VBR/CBR |
|
Audio Standard |
G.711-u/G.711-1/AAC |
|
Built-in Mic |
Yes, Audio Echo Cancellation |
|
Built-in Speaker |
Yes, Two-way audio |
|
Memory Slot |
Yes, maximum 512GB |
|
OSD Overlay |
Title and Tim overlay, Snapshot |
|
Smart Detection |
|
Motion Detection |
Support |
|
Target Detection |
Human and Vehicle Detection |
|
LED |
|
LED |
2 pcs IR & Warm light dual-wick LED |
|
Distance |
20 - 30 M |
|
Lens |
|
Focal Length |
F1.6 2.8 mm fixed lens |
|
Language |
|
English, simplified Chinese, Chinese Traditional, Deutsch, Italian, Turkish, Polish, Korean, Japanese, Russian, Ukrainian, Persian. |
|
Network Services |
|
Protocol |
HTTP / RTSP / FTP / NFSv3 / SMTP / DHCP / NTP / RTMP, etc. |
|
P2P |
Yes |
|
Web |
IE, Firefox, Chrome, Edge, Safari, etc. |
|
Media |
CMS, Android, IOS |
|
Face |
|
ONVIF |
17.06 compatible |
|
General |
|
Network Port |
1-RJ45, 100Mbps |
|
Power Supply |
12 VDC ± 10% |
|
PoE |
802.3af / at 48V |
|
Powr Consumption |
< 8W |
|
Operating Temp. |
-30°C (+60)°C, 10% - 90% RH |
