Key Features:
• Supports 16CH 8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/960P/720P/960H/DI/CIF IP video input
• Supports POS information overlay on live view, playback, and search
• Standard H.265 and H.264 high-profile compression format to get high-quality video at a much lower bit rate
• Intuitive and user-friendly Graphic User Interface (GUI), Windows-style operation by mouse
• Multi-mode recording: manual / timed / motion/sensor / POS / AI recording
• Playback: 16CH simultaneous playback
• Search: time slice, time, event, tag, and smart search
• Supports multiple VCA (Video Content Analytics) events, such as object abandonment/missing, region intrusion, tripwire, video tampering, etc.
• Express and flexible backup via USB, network, and so on
• Pentaplex: preview, record, playback, backup, and remote access
• DHCP, DDNS, PoE network protocol
• Remote control via Web Client or CMS: preview, playback, backup, PTZ, and configuration
• 16 PoE network ports; PoE power supply supported
• Dual stream technology for local storage with high definition, remote network transmission, and remote surveillance with a mobile device
• Multi-user online simultaneously
• Authorization management, log view, and device status view
• 4K ultra-high-definition output, true high-resolution display
• Supports NAT function and QRCode scanning by mobile phones
• Powerful mobile surveillance by smartphones with iOS and Android OS
Image Resolution Comparison
Configure your NVR to send immediate email notifications upon detecting motion
Access your system remotely from anywhere
Product Specifications:
|
Model |
CPV-SNVR16P-4K |
|
System |
|
Operating system |
Embedded Linux OS |
|
Video |
|
Network Input |
16CH IPC input |
|
Network Input Resolution |
8MP/ 6MP/ 5MP/ 4MP/ 3MP/ 1080P/ 1280X1024/ 960P/ 720P/ 960H/ D1/ CIF |
|
Output |
HDMI × 1: 3840 × 2160 / 1920 × 1080 / 1280 × 1024/ 1024 × 768 VGA: 1920 × 1080 / 1280 × 1024/ 1024 × 768
HDMI and VGA output the same video source |
|
Compression |
H.265 / H.264 |
|
Audio |
|
Network Input |
16CH IPC audio input |
|
2-way Audio |
RCA x 1 |
|
Local Output |
RCA x 1 |
|
Compression |
G.711 (U/A) |
|
Record |
|
Record stream |
Dual stream recording |
|
Resolution |
8MP/ 6MP/ 5MP/ 4MP/ 3MP/ 1080P/ 1280X1024/ 960P/ 720P/ 960H/ D1/ CIF |
|
Frame Rate |
NTSC: 30fps; PAL: 25fps |
|
Playback |
|
Simultaneous Playback |
Max: 16 CH |
|
Search |
Time slice/ time/ event/ tag/ smart search |
|
Smart Search |
Highlighted color to display the camera record in a certain period of time, different colors refer to different record events. |
|
Function |
Play, Pause, FF, FB, digital zoom, etc. |
|
Decoding Capability |
|
Live View/ Playback |
1CH 8MP; 4CH 1080P |
|
Alarm |
|
Mode |
manual, sensor, motion, exception, smart events |
|
Input |
Supports IPC alarm input |
|
Output |
Supports IPC alarm output |
|
Triggering |
Record, Snap, Preset, e-mail, etc. |
|
Network |
|
Interface |
RJ45 1000Mbps x 1 |
|
Protocol |
TCP/ IP, IPv4, IPv6, UDP, PPPoE, DHCP, DNS, DDNS, UPnP, NPT, HTTP, SMTP, HTTPs, 802.1x, ONVIF |
|
Incoming/Ougoing Bandwidth |
112/112 (Mbps) |
|
Client Connection |
Max. 10 Users' access |
|
LPR |
|
Plate Recognition |
Yes |
|
Mobile Device |
|
Operating System |
iOS, Android |
|
Storage |
|
HDD Interface |
SATA 3.0 x 2, max 8T per HDD |
|
Backup |
|
Local Backup |
U disk, USB mobile HDD |
|
Network Backup |
Yes |
|
Port |
|
USB |
USB 2.0 x 2 |
|
Remote Controller |
Yes |
|
PoE |
|
PoE Ports |
100M RJ45 x 16 |
|
Standards |
IEEE802.3AF |
|
Output Power |
≤ 150W |
|
Others |
|
Power Supply |
DC 48V/3.75A |
|
Consumption |
≤ 15W (without HDD) |
|
Dimensions (mm) |
380 x 264 x 45 (WxDxH) |
|
Working Environment |
-10 ~ 50 °C, 10% ~ 90% humidity |
|
Certificate |
CE, FCC |
|
Environmental Protection |
Complies with Directive EU RoHS, REACH and WEEE |
