We had made some of these for one of our customers who wanted OEM (to sell as their company brand) and we have some left from that order. They don't have the AVer logo on the DVR but all is firmware and the GUI has the AVer logo on it. These will also work with CMS3000, same remote client, and same PDA software for Android/iPhone. This is an authentic AVer product, with full warranty.
Part of our popular EH series, the new budget-friendly EH1004 DVR not only delivers a great price, but comes with better-than-standard features including full hybrid functionality, a robust Graphic User Interface and expanded remote management capabilities. User-friendly operation, low maintenance, essential surveillance functions and great value makes the EH1004 perfect for deployments in smaller facilities.
Model
EH1004H-4 Nano
System
Operating System
embedded Linux
Total channel number
4 channels
Max. IP camera input
4
Max. analog camera input
Performance
Display (analog)
120/100fps (NTSC/PAL)
Display (IP)
2M @ 6fps
Recording (analog)
compression
H.264
resolution
NTSC: 352 x 240 (CIF), 720 x 240 (Half-D1), 720 x 480 (D1)
PAL: 352 x 288 (CIF), 720 x 288 (Half-D1), 720 x 576 (D1)
frame rate (NTSC/PAL)
CIF: 120/100fps
Half-D1: 120/100fps
D1: 60/50fps
Recording (IP)
up to 5 megapixels for one channel, and a total of 8 megapixels for all 4 IP camera channels in H.264/MPEG-4/MJPEG format
Throughput
17.5 Mbps
Storage
internal HDD capacity
1 SATA HDD
internal RAID support
-
external HDD capacity
e-SATA HDD or RAID x 1
iSCSI support
Backup
internal DVD-RW
Interface
Monitor
VGA output
1 (1024 x 768)
HDMI output
TV output
1 (supports hybrid multi-quad output)
spot output
1 (supports full screen output from analog camera channels with triggered alarms)
Audio
input
4 line-in, 8 KHz sampling rate
ouput
1 line-out
MIC
no
Alarm
sensor (alarm) input
input voltage: max. DC 6V
relay output
1 (NO/NC)
voltage range: AC 125V / DC 30V
switching current: max. 1A
Network
Ethernet (RJ45)
1 port (10/100Base-T)
Connection
e-SATA
1
RS-232
1 (D-sub 9 pins, male)
RS-485
1 set (Tx+, Tx-, Rx+, Rx-)
USB 2.0
2 (on front panel)
Control
front key pad
LCD display
General
Electrical
power input
24W power adapter, DC 12V
Environmental
operating temperature
0°C to 40°C (32°F to 104°F)
operating humidity
90% RH
Mechanical
dimensions (W x H x D)
245 x 50 x 160 mm
weight (net)
0.8kg
Download Full Resolution PDF *Specification & Illustrations are subject to change without prior notice
