Video Features |
16 composite video inputs (BNC Connectors) and/or 16 IP camera (selected IP cameras), Max. of 16 video feed per system
8 audio input channels
Video Format: NTSC and PAL
Support 320x240, 640x480, or 720x480 (enhanced) pixels (NTSC & PAL) 16-bit true color
RCA composite video out to a regular terminal or TV monitor
Support static as well as dynamic de-interlacing for smoother graphics
Built in noise reduction algorithm
|
|
Display
|
Compact mode and advanced mode
Adjustable frame rate and resolution on each camera
Auto Scan with full screen display under 1, 4, 8, 9, 13, 16-camera display modes
Digital zoom into specific area
Pan/Tilt/Zoom (PTZ) cameras: PTZ script is available for adding new products
Auto Gain Control (AGC) balance image quality
Software based night view function enhances low light condition
|
|
Recording
|
Video compression: MPEG4
Video encryption supported
Supports 320x240, 640x480, and 720x480
D1 resolution recording in 320x240
Fully de-interlace in 640x480 and 720x480 mode
Recording modes: Alarm triggered/ sensor triggered/ motion detection/ continuous/ smart/ scheduled/ voice detection
Programmable multiple masking masking zones
Intelligent shield protects privacy
Capable of recording audio channel(s) with full synchronization
Max 8 audio channels recording
Auto recycling when storage nearing full
Intelligent pre-motion and post motion recording
Supports video encryption in Advanced MPEG4
|
|
Search & Playback & Backup
|
Real time playback without having to disable recording/ network functions
Powerful search: by date, time, camera, area, event, vision, POS text or log file
Full screen playback
Complete playback control: forward, backward, speed up, slow down
Digital zoom into any designated area
Export a single frame into a file or print out
Set a segment and have it output as avi video clip
Visual search by day, hour, minute, second
Bookmark search: by time, description, protect recorded file from being recycled and show file status
Direct backup to DVD-RW/CD-RW (requires Nero Ultra 6.0+)
|
|
Remote Web Access
|
Simultaneous multiple remote live/ recorded surveillance via Internet Explorer 6
Backup remotely
Center Management server controls multiple DVRs
Remote monitoring / remote recording / playback remote recording/ playback server recording
Full control of PTZ cameras remotely
PDA handy view (Windows CE / Pocket PC 2002 or above) / Windows 7 64 bit / Windows 10 64 bit
Two-way audio communication
1, 4 , 9 and 16 screen divisions
Remote E-map
Choose from dial-up, Internet or LAN speed
Dispatch server allows you to broadcast video stream to the public
|
|
Schedule
|
Record, enable network, backup, reboot and disabling alarms
One time or weekly schedule
Scheduling can be done down to every quarter of an hour
|
|
|
E-map
|
Showing the positions and status of camera, sensor, and relay
Extend to 8 maps
|
|
Alarm Notifications ( on motion detected, video loss and/or sensor triggered)
|
E-mail notifications
FTP notifications
Voice modem call out notification
Turn relay on (light switch, alarm, etc)
Plays warning sound (can be re-recorded)
Start recording on multiple cameras (capture video from different angle)
Send TV-out signals
Launch E-maps
Enlarge camera view
Send SMS/MMS (Requires SMS Modem)
Alert messages helps security follow proper standard operational procedures
|
|
User Access
|
Setup as many users as you like with their own individual passwords
Each user can be re-configured to perform only certain actions (e.g. access specific cameras remotely)
|
|
|
I/O Card
|
4 sensor inputs and 4 relay outputs control per set
|
|
